SecuEasy SE-RD628D - Digital Video Recorder 8 channel

Chargement...

Caractéristiques
Video	BNC 8CH In / 1CH Out, VGA output optional
Audio	RCA 8CH In/1CH Out
Compression Method	Video: H.264 compression
Recording Frame	PAL: 25f/s/ch NTSC: 30f/s/ch
Display Frame	PAL: 25f/s/ch NTSC: 30/s/ch
Recording resolution	CIF(4CH)
Network	1 RJ-45 10/100Mbps Ethernet connector
Recording Time	7~20 days with 500GB HD for Continuous Recording mode @ 25 fps
Recording Mode	Continuous, Motion detection, Sensor activated, Time schedule
Hard Disk Capacity	Up to 1TB, SATA interface HDD x 1
VGA Connector	For option
IR Remote Controller	Yes
Sensors, Alarm	4 Input, 1 Output (Alarm, option)
USB Mouse	Yes
USB Backup	USB 2.0 port for backup
PTZ Control	RS-232；RS-485
Power Supply	DC 12V，5A(Adapter Supplying)
Mobile Surveillance	Mobile Phone WAP protocol
Dimensions (L×W×H)	315mm x 224mm x 52mm
