- Converts fixed-to-mobile calls into cost-saving mobile-to-mobile calls
- Tens-of-thousands of installations with virtually no defective units
- Supports incoming calls from mobile users to the corporate PBX and VPN
- SIM Provider Lock secures the unit against unauthorized SIM cards
- Supports SIM card PIN protection Local configuration via DTMF
- Fixed network backup via mobile

Cost effective and amazingly reliable

The iGATE FCT does what we say it does, does it well, and that
saves your corporation money. We can say that because tens-ofthousands
of corporations have installed these small units and
have already saved hundreds-of-thousands of dollars.
Easy installation, no maintenance, and ongoing savings add up
to speedy ROI and make the iGATE FCT gateway a must for your
corporation. Small, but designed for heavy duty operation, by
converting fixed-to-mobile calls into mobile-to-mobile calls you
eliminate PTT charges.

Complete GSM compatibility

The leading mobile standard – GSM – is supported by the iGATE
FCT. This ensures seamless integration into the vast majority of
existing telecom infrastructures.
Also, the iGATE FCT operates via either 900/1800 MHz or
900/1900 MHz dual band GSM.
Convenient remote configuration
Eliminate costly maintenance by using remote SMS commands
to control the iGATE FCT 1 FXS. The iGATE FCT 1 FXS analyzes
your SMS message, executes the command, and replies to the
phone number you called from.

Premium suite of features

Features like Call Duration Limit, Toll Restriction, PIN Code Programming,
Calling Line Identification Restriction (CLIR), and too
many more to list, ensure that you can customize the iGATE FCT
to match the needs of your corporation.

Guaranteed voice quality

The iGATE FCT supplements mobile network voice quality with
configurable audio gain. The volume can be adjusted in both
directions: transmit and receive.

CAPABILITIES

Scalability 1 mobile channel
1 SIM
1 FXS
Advanced Network / Provider lock
PIN code restriction
Toll restriction
Echo cancellation Configurable
Call features Caller ID control (on outgoing calls only)
Call hold, call waiting, call duration limitation
Immediate dialing

PROTOCOLS

Mobile GSM: Dual band (900/1800 800/1900 MHz)
Data port RS232, AT command compatible

SYSTEM MANAGEMENT

DTMF management
SMS management

PHYSICAL PARAMETERS

Size (W × H × D ) 64 × 33.4 × 165 mm
Power supply 100–240 VAC, 50–60 Hz
Supply voltage 9 VDC, 1 A
Consumption 6 W

Connection specifications

Telephony RJ11-C (pin2,3-TIP, pin4, 5-RING)
Antenna SMA
Line loop current 40 mA max
Line supply voltage -48 VDC ± 10 %
Line impedance 600 Ohm
Dial tone 400 Hz ± 1 %
Ring generator 42 Vrms/25 Hz
Line signaling DTMF
Disconnect signal Reverse polarity, Pulse drop

ENVIRONMENTAL CONDITIONS

Temperature 0 °C to +40 °C
