Description du produit

Model

  KD-818

Channel

  8CH

Video Input Format

  NTSC / PAL : BNC 8CH In / 2CH Out

Display Speed   (Full Mode)

  NTSC : 240 fps ; PAL: 200 fps (8 x 25 fps)

Recording Speed (Full Mode)

  NTSC : Max. 60 frame per second. ; PAL : Max. 50 frame per  second.

Recording Speed (Each Mode)

  NTSC : 1 fps ~ Max. 30fps ; PAL : 1 fps ~ Max. 25 fps adjustable (Each Mode)

Compression Method

  Enhanced MJPEG (12-20K Bytes per frame)

  Video Quality: Low@12KBytes ; Normal@15KBytes ; High@20KBytes

Hard Disk Capacity

  Over 500G Bytes , ATA-100 interface HDD x 2

Recording Time

  10 days with 500GB HD @ 25 fps for Continuous Recording mode.

Recording Mode

Sensors, Alarm

  8 Input, 1 Output (Alarm) (16 Pin DIP Switch), 2 Pin for RS485 control Pan/Tilt/Zoom

Audio ( 1CH in , 1CH Out )

  Yes

Network (RJ45) IE view only

  Yes

USB port for media Backup

  Yes

PTZ (RS485 Interface)

  Yes

IR Remote Control Unit

  Yes

VGA output ( 1CH )

  -----

Power Input

  DC12V, 5A (Adapter supplying)

Dimensions (L*W*H)

  400 X 276 X 69 mm
