Visio KD-608 - DVR with 8 CH M-JEPG
Chargement... FICHE TECHNIQUE
Description du produit | ||
| Model |
KD-608 | |
| Compression Format |
Motion JPEG | |
| Video Output |
BNC 2-channel, S-Video 1-channel | |
| Video Input |
BNC8-channel | |
| Display Resolution |
NTSC: 720×480 PAL: 720×576 | |
| Recording Resolution |
NTSC: 720×240 / 360×240 PAL: 720×288 / 360×288 | |
| Display Frame Rate | NTSC |
240fps/ 8×30fps |
| PAL | 200fps/ 8×25fps | |
| Record Frame | NTSC | Max.120fps/8×15fps |
| Rate | PAL |
Max.100fps/8×12.5fps |
| Audio Input |
-8dB --- 22k, RCA×4 | |
| Audio Output |
-8dB --- 92dB, RCA× 2 | |
| Sensor Input |
NO or NC, 8-channel | |
| Relay Alarm Output |
NO or NC, 1-channel | |
| Recording Mode |
24 hrs.×7 days schedule, motion detection, sensor or network triggered | |
| Simplex/Duplex/Triplex |
Triplex | |
| Network Interface |
RJ45 for LAN & Internet | |
| VGA Output |
Optional | |
| PTZ Control |
RS485, 4 protocols (PELCO-D, PELCO-P, NEON&SAMSUNG) supported | |
| HDD Capacity |
Default: One removable caddy + one fixed rack | |
|
Option: One CD-RW+ one fixed rack | ||
| Remote |
Included | |
| Power |
DC12V/ 5A (Adaptor Supply) | |
| Storage |
-20~65℃ / 20~95%RH | |
| Operation |
-5~50℃ / 20~85%RH | |
| Dimension ( Lx Wx H ) |
430x385x65mm | |
