Video System

PAL

Video Compression Format

H.264

Video Input

8 Channels. Composite video signal 1 Vp-p 75Ω BNC

Video Output

Main Monitor Output: Composite video signal 1 Vp-p 75Ω BNC

Audio Input / Output

4 audio inputs, 1 audio output (Mono)

Maximum Recording Rate

Frame: 704×576 pixels with 50 IPS

Field: 704×288 pixels with 100 IPS

CIF: 352×288 pixels with 200 IPS

Adjustable Recording Speed

Frame: 50, 25, 12, 6 IPS

Field: 100, 50, 25, 12 IPS

CIF: 200, 100, 50, 25 IPS

Image Quality Setting

SUPER BEST / BEST / HIGH / NORMAL

Hard Disk Storage

Accommodates 2 SATA HDD (capacity up to 2TB)

Quick Search

Time / Motion / Alarm search mode

SATA Interface

Built-in

VGA Interface

Built-in (output resolution up to 1600 x 1200)

Recording Mode

Manual / Timer / Motion / Alarm / Remote

Multiplex Operation

Live display / record / playback / backup / network operations

USB Mouse Control

YES

Motion Detection Area

16 × 12 grids per channel

Motion Detection Sensitivity

3 adjustable parameters for accurate detection

Pre-alarm Recording

YES

Backup Device

USB 2.0 flash drive / Network

Web Transmitting Compression Format

H.264

Ethernet

10/100 Base-T. Supports remote control and live view via Ethernet

Web Interface

Licensed software “Video Viewer” / Internet Explorer, Mozilla Firefox or Google Chrome web browser / QuickTime player
(5 users access simultaneously)
*Operating System: Windows 7 / Vista / XP / 2000

Network Protocol

TCP/IP, PPPOE, DHCP and DDNS

Fully Remote Independent Operation

YES

Event Notification

By FTP & E-Mail

IR Remote Control

YES (IR receiver built-in)

Mobile Surveillance

YES (Including iPhone & BlackBerry)

Picture Zoom

2X digital zoom

PTZ Control

YES

Alarm I/O

8 inputs, 1 output

Key Lock (Password Protection)

YES

User Level

Administrator & Operator

Video Loss Detection

YES

Camera Title

Supports up to 6 letters

Video Adjustable

Hue / Saturation / Contrast / Brightness

Date Display Format

YY/MM/DD, DD/MM/YY & MM/DD/YY

Daylight Saving

YES

Power Source (±10%)

DC 19V

Power Consumption (±10%)

＜64 W

Operating Temperature

10℃ ~ 40℃ (50℉~104℉)

Dimensions (mm)

430(W) x 65(H) x 338(D)

System Recovery

System auto recovery after power failure

Optional Peripherals

Keyboard Controller
