Cisco VWIC3-2MFT-T1/E1 - VWIC3-2MFT-T1/E1 Cisco Voice/WAN Card

Manufacturer
Cisco
Part Number
VWIC3-2MFT-T1/E1
Device Type
Interface module
Form factor
2-Port T1/E1 Multiflex Trunk Voice/WAN Interface Card
Specifications
Number of Ports
2
T1 Support
Yes
E1 Support
Yes
Unstructured E1 (G.703) Support
No
Data Support WIC Mode
Yes
Voice Support VIC*
Yes
Drop-and-Insert Multiplexing
Yes
Configuration Comparison
Serial Data (channel-group*)
2 total
2 per port
Voice CAS (ds0-group**)
48 total (T1)
62 total (E1)
1 per timeslot
PRI (pri-group***)
2 total
1 per port
Drop & Insert (tdm-group****)
48 total (T1)
62 total (E1)
1 per timeslot
Network Management Features
Telnet or Console
Remote and local configuration, monitoring, and troubleshooting from Cisco IOS Software CLI
Simple Network Management Protocol (SNMP)
• Router and DSU/CSU managed by single SNMP agent; router, DSU, and CSU appear as a single network entity to user
• Standard MIB (MIB II)
• Cisco Integrated DSU/CSU MIB
• RFC 1406 T1 MIB, Including Alarm Detection and Reporting
SNMP Traps
Generated in response to alarms
