Visio KD-D3204M - Standalone DVR H.264 DVRs High Performance Embedded Rocessor

Chargement...

-39%

Standalone DVR H.264 DVRs High Performance Embedded Rocessor

Support MPEG4/H.264 video compression Support 4CH playback simultaneously Support PPPoE etc Support adjust split screen size by mouse Support multi mode Support 3 USB2.0 Support matrix output(operational)

Ce produit n'est plus proposé à la vente

Disponibilité : Obsolète (Fin de vie)

Evaluation :

Evaluer ce produit.

Description
Avis des clients

FICHE TECHNIQUE

Description du produit
MODEL	KD-D3204M
Main processor	High Performance Embedded Rocessor
Operation system	VxWorks embedded RTOS
VIDEO
Format	NTSC/PAL
Compression	MPEG4/H.264
Input	32CH BNC(1.0Vp-p,75Ω)
Main output	2CH BNC(1.0Vp-p,75Ω), 1CH VGA(800×600,1024×768,1280×1024)
Matrix output	4CH BNC(1.0Vp-p,75Ω)
AUDIO
Compression standard	G.723/ADPCM
Input	16CH, BNC(linear voltage,10KΩ)
Ouput	1CH, BNC(linear voltage,600Ω)
Voice Communication	independent CH for 2 way voice communication(miniJACK)
DISPLAY
Resolution	D1 704×576(PAL) 704×480 (NTSC)
Frame rate	25(PAL)/30(NTSC)FPS
Division	1/4/6/9/13/16/25/36CH, Digital Zoom
RECORD
Resolution	CIF 352×288(PAL)　352×240(NTSC)
Frame rate	25(PAL)/30(NTSC)FPS, all real time, flexible
Quality	5 Levels(Low, Normal, Good, Fine, Super)
Mode	Manual/Schedule/Motion detection/Alarm Sensor/Event/Prerecord/Auto start record
Playback	Support 4CH simultaneously playback
HDD
Basic storage	6 SATA HDD Capacity, Max.:2T/HDD, independent operation indicates light
ALARM
Input	12CH
Output	3 CH
OTHER
System resource	Multi-CH recording, playback,monitoring and network operation simultaneously
Network	RJ45, auto adapt 10/100M Ethernet Support PPPoE
Comunication Port	1 RS232 port, 1RS485 port, 1RS422 port, 3 USB2.0 port
Backup	Removable HDD, USB DVD/CD writer, Network
Power supply	AC100-240V 50/60Hz
Unit weight	15KG
Dimensions(W×H×D)	440×100(including standing points)×460 mm, 2U
Shipping dimensions(W×H×D)	538×538×253 mm, 2U
