Visio KD-D3204 - Standalone DVR H.264 DVRs High Performance Embedded Rocessor
Chargement... FICHE TECHNIQUE:
Description:
MODEL
KD-D3204
Main processor
High Performance Embedded Rocessor
Operation system
VxWorks embedded RTOS
VIDEO
Format
NTSC/PAL
Compression
MPEG4/H.264
Input
32CH BNC(1.0Vp-p,75Ω)
Main output
2CH BNC(1.0Vp-p,75Ω), 1CH VGA(800×600,1024×768,1280×1024)
Matrix output
N/A
AUDIO
Compression standard
G.723/ADPCM
Input
16CH, BNC(linear voltage,10KΩ)
Ouput
1CH, BNC(linear voltage,600Ω)
Voice Communication
independent CH for 2 way voice communication(miniJACK)
DISPLAY
Resolution
D1 704×576(PAL) 704×480 (NTSC)
Frame rate
25(PAL)/30(NTSC)FPS
Division
1/4/6/9/13/16/25/36CH, Digital Zoom
RECORD
Resolution
CIF 352×288(PAL) 352×240(NTSC)
Frame rate
25(PAL)/30(NTSC)FPS, all real time, flexible
Quality
5 Levels(Low, Normal, Good, Fine, Super)
Mode
Manual/Schedule/Motion detection/Alarm Sensor/Event/Prerecord/Auto start record
Playback
Support 4CH simultaneously playback
HDD
Basic storage
6 SATA HDD Capacity, Max.:2T/HDD, independent operation indicates light
ALARM
Input
12CH
Output
3 CH
OTHER
System resource
Multi-CH recording, playback,monitoring and network operation simultaneously
Network
RJ45, auto adapt 10/100M Ethernet Support PPPoE
Comunication Port
1 RS232 port, 1RS485 port, 1RS422 port, 3 USB2.0 port
Backup
Removable HDD, USB DVD/CD writer, Network
Power supply
AC100-240V 50/60Hz
Unit weight
15KG
Dimensions(W×H×D)
440×100(including standing points)×460 mm, 2U
Shipping dimensions(W×H×D)
538×538×253 mm, 2U
