Visio KD-D2404M - Standalone DVR H.264 DVRs High Performance Embedded Rocessor
Chargement... Avis
FICHE TECHNIQUE:
Description du produit | |
| MODEL | KD-D2404M |
| Main processor | High Performance Embedded Rocessor |
| Operation system | VxWorks embedded RTOS |
VIDEO | |
| Format | NTSC/PAL |
| Compression | MPEG4/H.264 |
| Input | 24CH BNC(1.0Vp-p,75Ω) |
| Main output | 2CH BNC(1.0Vp-p,75Ω), 1CH VGA(800×600,1024×768,1280×1024) |
| Matrix output | 4CH BNC(1.0Vp-p,75Ω) |
AUDIO | |
| Compression standard | G.723/ADPCM |
| Input | 16CH, BNC(linear voltage,10KΩ) |
| Ouput | 1CH, BNC(linear voltage,600Ω) |
| Voice Communication | independent CH for 2 way voice communication(miniJACK) |
DISPLAY | |
| Resolution | D1 704×576(PAL) 704×480 (NTSC) |
| Frame rate | 25(PAL)/30(NTSC)FPS |
| Division | 1/4/6/9/13/16/25/36CH, Digital Zoom |
RECORD | |
| Resolution | CIF 352×288(PAL) 352×240(NTSC) |
| Frame rate | 25(PAL)/30(NTSC)FPS, all real time, flexible |
| Quality | 5 Levels(Low, Normal, Good, Fine, Super) |
| Mode | Manual/Schedule/Motion detection/Alarm Sensor/Event/Prerecord/Auto start record |
| Playback | Support 4CH simultaneously playback |
HDD | |
| Basic storage | 6 SATA HDD Capacity, Max.:2T/HDD, independent operation indicates light |
ALARM | |
| Input | 12CH |
| Output | 3 CH |
OTHER | |
| System resource | Multi-CH recording, playback,monitoring and network operation simultaneously |
| Network | RJ45, auto adapt 10/100M Ethernet Support PPPoE |
| Comunication Port | 1 RS232 port, 1RS485 port, 1RS422 port, 3 USB2.0 port |
| Backup | Removable HDD, USB DVD/CD writer, Network |
| Power supply | AC100-240V 50/60Hz |
| Unit weight | 15KG |
| Dimensions(W×H×D) | 440×100(including standing points)×460 mm, 2U |
| Shipping dimensions(W×H×D) | 538×538×253 mm, 2U |
| Poids | |
| Dimensions |
