| Mpodel |
KD-NMP100 (Wired) |
| Sensor |
1/3 inch CMOS, Minimum illumination 1 Lux |
| Auto Iris |
DC drive (CMOS NOT SUPPORTED) |
| Video resolution |
1600 x 1200,1280x960,1280 x 720, 800 x 600 |
| Video parameters |
Brightness, hue, contrast, saturation and image quality |
| Streaming Format |
Video Streaming or Audio &Video composite Streaming |
| Video Frame Rate |
1600 x 1200 |
| 1280 x 960 |
| 1280 x 720 |
| 800 x 600 |
| Video Compression Bit rate |
16Kbit/S～8Mbit/S |
| Video output |
1channel composite video output (CMOS NOT SUPPORTED) |
| Audio Input |
1channel,linear input, Input Impedance:1KOhms |
| Audio Compression |
G.726 |
| Audio Output |
1channel, linear output, |
| two-way talk input |
Support Audio two-way talk |
| Image Encrypting |
Digital watermarking,AES Encrypt |
| Local recording |
SD card recording and snapshot |
| Support IP-San storage |
| Supported Protocols |
TCP, UDP, IP, HTTP, FTP, SMTP, DHCP, DNS,ARP, ICMP, POP3, NTP, Ipsec, UpnP, RTP, RTCP |
| System Interface |
10Base-T/100Base-TX Ethernet port |
| 1 RS485 |
| Support mobile suveillance |
| Alarm input |
1channel on/off input, support NO (open) or NC (closed) |
| RFID technology，link with wireless detectors |
| Alarm output |
1 channel on/off, 120VAC 1A/24VDC 1A |
| Power supply |
DC 12V 1A |
| Power consumption |
6W Max |
| Work humidity |
RH85%MAX |
| Dimension |
14cm(L)*5.5cm(W)*6.3cm(H) |
| Net weight |
0.42kg |
