Description

Standard : Video: PAL; NTSC Audio: G.711A

Video Compression : H.264(High Pro_le)

Video Display : 1/4 split display

Video Input : 1080P:4-ch

Video Output : 1-ch BNC, 1-ch VGA, 1-ch HDMI

Audio Output : 1-ch RCA

Backup/Playback

Backup : Network backup, USB mobile hard disk

Local Playback : 960P:1-ch

Playback Resolution : 960P/720P/960H/D1/HD1/CIF/QCIF

Hard Disk Driver

Storage : 1 SATA (Max 3TB)

ExternalInterface                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                   Network Interface : 5 RJ45 10M/100M POE adaptive Ethernet Interface

USB Interface : 2 USB ports

Serial Interface : 1 RS-485 half-duplex interface

General

Working Conditions : 0℃-＋55℃; 10%－90% RH

Power Supply : 12V/3A; 48V/1.5A

Dimension(color box) : 345mm*95mm*275mm

Net/Gross Weight : 1kg/1.88kg
